Zurn® Wilkins 38-ZW3870XLT-4P 50247
Send Print

Zurn® Wilkins 38-ZW3870XLT-4P

Zurn® Wilkins Aqua-Gard® 38-ZW3870XLT-4P Thermostatic Mixing Valve With 4-Port, 3/8 in, Compression, 145 psi, 3.1 gpm Flow, Cast Bronze Body

  • MPN: 38-ZW3870XLT-4P
  • TPN: 50247
  • UPC: 612052077772
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Sold As: EACH
  • Login to see Availability

Zurn® Wilkins Aqua-Gard® Lead-Free Thermostatic Mixing Valve, Series: ZW3870XLT, 3/8 in Nominal, Compression, 145 psi, 120 to 195 deg F Hot Supply/40 to 75 deg F Cold Supply, 3.1 gpm Flow, Media: Water, 5-55/64 in Inlet to Outlet Length, 2-27/32 in Top to Inlet Center, Cast Bronze Body, 300 Stainless Steel Spring Trim, FKM Seal/Noryl GFN2 Guide Tube/Acetal Co-Polymer Checks, Nickel Plated, 4-27/32 in H

Series      :      ZW3870XLT
Nominal Size      :      3/8 in
End Style      :      Compression
Pressure Rating      :      145 psi
Temperature Rating      :      120 to 195 deg F Hot Supply/40 to 75 deg F Cold Supply
Flow Capacity      :      3.1 gpm
Media      :      Water
Inlet to Outlet Length      :      5-55/64 in
Top to Inlet Center      :      2-27/32 in
Body Material      :      Cast Bronze
Trim Material      :      300 Stainless Steel Spring
Softgoods Material      :      FKM Seal/Noryl GFN2 Guide Tube/Acetal Co-Polymer Checks
Finish      :      Nickel Plated
Dimensions      :      4-27/32 in H
  • High protection from scalding injuries with precise temperature control
  • pdf Catalog https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Zurn_12ZW1017XL2PEX1C_Catalog.pdf
  • pdf Warranty Information https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Zurn_P12-BG_Warranty.pdf
  • pdf Instruction/Installation Manual https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Zurn_Wilkins_38-ZW3870XLT-4P_Installation_Manual.pdf
  • pdf Specification Sheet https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Zurn_Wilkins_38-ZW3870XLT-4P_Specification_Sheet.pdf

The 3/8" ZW3870XLT-4P Aqua-Gard® Thermostatic Mixing Valve with 4 ports (1 hot in, 1 cold in, 1 cold out, 1 mixed out) is utilized in both residential and most light commercial point-of-use installations with 3/8” compression fittings to protect against potential scalding from hot water. The ZW3870XLT valve has a rapid response rate and precise temperature control to meet the stringent ASSE 1070 standards for installation on fixtures, sinks, lavatories, or bathtubs. It mixes hot and cold water for a final safer water temperature outlet range of 95° to 115°F. The ZW3870XLT-4P includes 4 ports (1 hot in, 1 cold in, 1 cold out, 1 mixed out).
