WATTS® 0556031

WATTS® 0556031 N36 Low Profile Vacuum Relief Valve, 3/4 in Nominal, MNPT End Style, 15 psi Pressure, 15 cfm Flow Rate, Brass Body, Import

  • MPN: 0556031
  • TPN: 45820
  • UPC: 098268450415
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Sold As: EACH
  • Login to see Availability

WATTS®, 0556031, Vacuum Relief Valve, Low Profile, Series: N36, 3/4 in Nominal, MNPT End Style, 15 psi Pressure, 250 deg F, 15 cfm Flow Rate, Brass Body, Buna-N® O-Ring/Silicon Disc Softgoods, 2 in H x 2 in W Dimensions, Import

Type      :      Low Profile
Series      :      N36
Nominal Size      :      3/4 in
End Style      :      MNPT
Pressure Rating      :      15 psi
Temperature Rating      :      250 deg F
Flow Rate      :      15 cfm
Body Material      :      Brass
Softgoods Material      :      Buna-N® O-Ring/Silicon Disc
Dimensions      :      2 in H x 2 in W
Domestic/Import      :      Import
  • Lead free construction
  • Maximum temperature 250 deg
  • pdf Instruction/Installation Manual https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/WATTS_556031_Installation_Manual.pdf
  • pdf Specification Sheet https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/WATTS_556031_Specification_Sheet.pdf

This 3/4 inch lead free vacuum relief valve is suitable for low pressure steam and water service, and is ideal for use in domestic water heaters and supply tanks. This valve automatically allows air to enter into the piping system to prevent vacuum conditions that could siphon water from the system and damage water equipment. It consists of a lead free brass body construction with NPT male inlet connection, and a protective cap. Maximum working pressure is 200 psi.
