Delta® 9183-AR-DST 74576
Send Print

Delta® 9183-AR-DST

DELTA® 9183-AR-DST Mateo® Kitchen Faucet, 1.8 gpm Flow Rate, Arctic™ Stainless Steel, 1 Handles, 1/3 Faucet Holes, Function: Traditional, Domestic, Commercial

  • MPN: 9183-AR-DST
  • TPN: 74576
  • UPC: 034449802963
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Login to see Availability

DELTA® Kitchen Faucet, Mateo® Collection, 1.8 gpm Flow Rate, 8 in Center Distance, Pull-Down Spout, 9-1/4 in Spout Reach, 15-1/2 in Spout Height, 62 in Hose, Lever Handle, 1 Handles, 1/3 Faucet Holes, 1-1/4 in Faucet Hole, 3/8 in Connection, Compression Connection, Spray Pattern: Aerated Stream/Full Body, Function: Traditional, 2 Spray Functions, 2-1/2 in Maximum Deck Thickness, Deck Mounting, Euro-Motion DIAMOND™ Seal Valve, 2-1/16 in W x 9-1/4 in D x 15-1/2 in H, Metal, Arctic™ Stainless Steel, Domestic, Commercial Commercial/Residential

Collection      :      Mateo®
Flow Rate      :      1.8 gpm
Center Distance      :      8 in
Spout Type      :      Pull-Down
Spout Reach      :      9-1/4 in
Spout Height      :      15-1/2 in
Hose Size      :      62 in
Handle Style      :      Lever
Number of Handles      :      1
Number of Faucet Holes      :      1/3
Faucet Hole Size      :      1-1/4 in
Connection Size      :      3/8 in
Connection Type      :      Compression
Spray Pattern      :      Aerated Stream/Full Body
Number of Spray Functions      :      2
Maximum Deck Thickness      :      2-1/2 in
Mounting Type      :      Deck
Valve/Cartridge Type      :      Euro-Motion DIAMOND™ Seal Valve
Dimensions      :      2-1/16 in W x 9-1/4 in D x 15-1/2 in H
Material      :      Metal
Finish/Color      :      Arctic™ Stainless Steel
Domestic/Import      :      Domestic
Commercial/Residential      :      Commercial
  • 62 in L hose provides outstanding reach
  • 3/8 in OD straight, staggered PEX supply tubes
  • Red blue indicator marking
  • Dual integral check valves in sprayer assembly
  • 1.8 gpm at 60 psi
  • MagnaTite Docking uses a powerful integrated magnet to snap your faucet spray wand precisely into place and hold it there so it stays docked when not in use and doesn't droop over time
  • ShieldSpray Technology powers off the mess without making a mess
  • Concentrated stream cuts through messes and innovative water shield reduces splatter
  • Soft, rubber Touch-Clean spray holes allow you to easily wipe away calcium and lime build-up with the touch of a finger
  • DIAMOND Seal Technology is less hassle to install and helps your faucet perform like new for life, reducing leak points and lasting twice as long as the industry standard
  • Everything you need is together in one convenient box, including integrated InnoFlex PEX supply lines
  • 1 or 3-hole 6 in or 8 in installation
  • pdf Instruction/Installation Manual https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/DELTA_16968-SSSD-DST_Installation_Manual.pdf
  • pdf Full Engineering Drawing https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/DELTA_9183-DST_Full_Engineering_Drawing.pdf
  • pdf Specification Sheet https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/DELTA_9183-DST_Specification_Sheet.pdf
  • pdf Line Drawing https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://externalassets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/Delta_Faucet_Co_9983-DST_Line_Drawing.pdf

Inspired by the graceful curves of blown glass bottles, the Delta Mateo Collection lends a transitional, dynamic touch to any space.
