Saniflo® Macerator Pump, 1.28 gpf Flow Rate, 2 in Inlet, 0.5 hp, 115 VAC, 4.5 A, 60 Hz Frequency, 104 deg F, 18-3/4 in W x 6-3/4 in D x 10-3/4 in H

• The Saniaccess® 2 is ideal to create an additional half-bathroom anywhere
• For half bathroom applications
• 15 ft vertical and/or 150 ft horizontal discharge
• Quietest pump on the market
• Easy dual access service panels
• Discharges the waste through a 3/4 or 1 in rigid pipe
• Non-return valve is included on the discharge elbow assembly provided with the system
• Elbow can be rotated 360 deg depending on the discharge installation
• Has been designed with a 1-1/2 in vent connection on the top of the lid
• All plumbing codes require connection to a vent system
• Must be connected to Saniflo® 1.28 gpf rear discharge toilet
• Will also discharge gray water from any sink, bath/shower or urinal
• Wastewater will drain into the system via two 2 in inlets with built-in check valves on either side of the housing, note that when adding a bathtub/shower, the base should be raised up by a minimum of 6 in off the floor
• 0.5 hp oil-filled thermally protected motor
• 45 uF capacitor
• 51 in power cord
• ≤ 53 dBA noise level measured at 3 ft

The Saniaccess®3 is a 1/2 hp pump system used to install a complete bathroom up to 15 ft below the sewer line or even up to 150 ft away from a soil stack. It incorporates a macerating system which can handle human waste and toilet paper in residential applications. The blade is made out of a hardened stainless steel material which eliminates the need for any service or replacement.
