Spears® TPC-010-S 31277
Send Print

Spears® TPC-010-S

Spears® EverTUFF® TPC-010-S Transition Adapter, 1 in, CTS Socket x PEX Barb-Crimp, CPVC, Domestic

  • MPN: TPC-010-S
  • TPN: 31277
  • UPC: 054211108376
  • Min Order Qty: 1
  • Quantity Interval: 1
  • Login to see Availability

Spears® EverTUFF® Transition Adapter, Fitting/Connector Type: Adapter, 1 in Nominal, CTS Socket x PEX Barb-Crimp, 2-9/32 in Length, 100 psi, Molded, CPVC, Tan, 73 deg F, 1-7/16 in Dia, Domestic

Fitting/Connector Type      :      Adapter
Nominal Size      :      1 in
End Style      :      CTS Socket x PEX Barb-Crimp
Length      :      2-9/32 in
Pressure Rating      :      100 psi
Method of Manufacture      :      Molded
Material      :      CPVC
Color      :      Tan
Temperature Rating      :      73 deg F
Dimensions      :      1-7/16 in Dia
Domestic/Import      :      Domestic

Spears® Copper Tube Size (CTS) fittings are manufactured from chlorinated polyvinyl chloride (CPVC) for use with SDR-11 piping systems of CTS outside diameter in hot and cold water distribution systems. Check state and local codes for application and restrictions.
