Aquatic Bathtub, 1-Piece Integral Skirted, Everyday, Soaking Bath Therapy, Oval Shape, 60 in Width, 26-1/4 in Height, 67 gal Water, Left Drain Location, 1/2 in Drain Height, 2 in Dia Drain, 12-5/8 in Soaking Depth, 12-1/8 in Overflow Height, Gel-Coated/White, Domestic
| Type | : | 1-Piece Integral Skirted |
| Collection | : | Everyday |
| Bath Therapy Type | : | Soaking |
| Shape | : | Oval |
| Width | : | 60 in |
| Height | : | 26-1/4 in |
| Water Capacity | : | 67 gal |
| Drain Location | : | Left |
| Drain Height | : | 1/2 in |
| Drain Size | : | 2 in Dia |
| Soaking Depth | : | 12-5/8 in |
| Overflow Height | : | 12-1/8 in |
| Finish/Color | : | Gel-Coated/White |
| Domestic/Import | : | Domestic |
- 66 deg backrest slope
- 17.5 in H skirt
- Textured tile
- Integral tiling flange (3T)
- 8 in wainscoat
- Ergonomic backrest
- 16.375 in H sump
- Sump width at centerline: 51-1/8 in top x 41-5/8 in bottom
- Sump depth at centerline: 34-1/2 in top x 29 in bottom
- Top of drain to bottom of overflow: 12-1/8 in
- Drain rough-in (from side wall): 3-1/4 in
- Drain rough-in (from back wall): 21-3/4 in
- 43-1/4 in D x 60-1/8 in W x 26 in H alcove frame
- 42 in D
- Alcove installation
- 67 gal minimum operating capacity
- Textured tile finish
