PVC fittings are for drain, waste and vent purposes. They are used in gravity-fed waste elimination systems and are for Non-Pressure systems where temperatures will not exceed 140 deg F. PVC is lightweight and easy to install. They require no special tools for cutting, and can be installed with solvent cementing, threading, flanging, and roll-grooved joining. All Charlotte Pipe products are manufactured in the USA.
Charlotte DWV Street Bend, 22-1/2 deg Elbow Fitting/Connector, 10 in Nominal, Spigot x Hub End Style, SCH 40/STD Schedule, 150 psi Pressure, Fabricated Method of Manufacture, PVC, White, 140 deg F, Domestic
|
Series
|
:
|
D Series
|
|
Fitting/Connector Type
|
:
|
22-1/2 deg Elbow
|
|
Nominal Size
|
:
|
10 in
|
|
End Style
|
:
|
Spigot x Hub
|
|
Length
|
:
|
13-13/16 in
|
|
Schedule Rating
|
:
|
SCH 40/STD
|
|
Pressure Rating
|
:
|
150 psi
|
|
Method of Manufacture
|
:
|
Fabricated
|
|
Material
|
:
|
PVC
|
|
Color
|
:
|
White
|
|
Temperature Rating
|
:
|
140 deg F
|
|
Dimensions
|
:
|
11-17/32 in OD x 16 in H
|
|
Domestic/Import
|
:
|
Domestic
|
- Not intended for pressure use
- For use where systems will not exceed 140 deg F
- Lightweight, easy to install
- Requires no special tools for cutting and is installed by solvent cementing
-
