InSinkErator Badger 5 garbage disposals are a reliable and functional choice when affordability is the prime concern. Choose from three Badger series garbage disposal models, each with a space-saving compact design.
Insinkerator® Garbage Disposal, Continuous Feed, Series: Badger® 5, 1-1/2 in Drain Connection, 1/2 hp, 120 VAC, 6.3 A, 60 Hz Frequency, 1725 rpm Grinding Speed, 26 oz Grinding Chamber, Sink Mounting, ON/OFF Control, Galvanized Steel, Waterborne Grey Enamel, 6-5/16 in W x 12-5/8 in H, Domestic
| Type | : | Continuous Feed |
| Series | : | Badger® 5 |
| Drain Connection | : | 1-1/2 in |
| Horse Power | : | 1/2 hp |
| Voltage Rating | : | 120 VAC |
| Amperage Rating | : | 6.3 A |
| Frequency Rating | : | 60 Hz |
| Grinding Speed | : | 1725 rpm |
| Grinding Chamber Capacity | : | 26 oz |
| Mounting Type | : | Sink |
| Control Type | : | ON/OFF |
| Material | : | Galvanized Steel |
| Finish | : | Waterborne Grey Enamel |
| Dimensions | : | 6-5/16 in W x 12-5/8 in H |
| Domestic/Import | : | Domestic |
- 1/2 hp Dura-Drive® induction motor, single phase
- Quick Lock® sink mount allows for easy installation and garbage disposal replacement
- On/Off control - Wall switch
- Intermittent time rating
- Permanently lubricated upper and lower bearings
- Manual reset overload motor protection
- 1 gal per person/day average water usage
- 3 to 4 kWh per year average electrical usage
- Anti-vibration drain connection (hose clamp)
