Aquatic Tub Shower Stall, 1-Piece, Series: FreedomLine 2603SMTER, Accessible, Squared Shape, 56 in Length, 30-3/4 in Width, 76 in Height, 56 in W Opening, Right Drain Location, 4 Grab Bars, 2 in Drain Connection, Alcove Mounting, Gel-Coated/White
Type
|
:
|
1-Piece
|
Series
|
:
|
FreedomLine 2603SMTER
|
Collection
|
:
|
Accessible
|
Shape
|
:
|
Squared
|
Length
|
:
|
56 in
|
Width
|
:
|
30-3/4 in
|
Height
|
:
|
76 in
|
Opening Size
|
:
|
56 in W
|
Drain Location
|
:
|
Right
|
Number of Grab Bars
|
:
|
4
|
Drain Connection
|
:
|
2 in
|
Mounting Type
|
:
|
Alcove
|
Finish/Color
|
:
|
Gel-Coated/White
|
- Right drain location
- Smooth wall finish
- Partial reinforcement to accommodate standard grab bar locations
- AcrylXâ„¢ applied acrylic surface
- Skirt height: 17 in
- Sump width (top): 23-1/4 in
- Sump depth (top): 53-3/4 in
- Sump width (bottom): 21-1/4 in
- Sump depth (bottom): 45-1/4 in
- Sump height: 13-5/8 in
- Soaking depth: 9-3/4 in
- Capacity to overflow: 38 gal
- Backrest slope: 56 deg
- Deck height: 17 in
- Tub drain location (from back wall): 15 in
- Tub drain location (from side wall): 8-1/2 in
- Drain clearance: 2-3/4 in
- Overflow height: 11-1/8 in
- Stub up (from side wall): 1-1/2 in
- Stub up (from back wall): 15 in
-
