This ultra high efficiency, low-consumption universal urinal operates in the range of 0.125 to 1 gpf. Choose a manual or Selectronic® sensor-operated flush valve that suits your budget and water usage requirements. Features include a flushing rim and washout flush action for effectiveness, plus extended sides for privacy.
American Standard Urinal, Universal, Washbrook™ FloWise® Collection, 0.125/1 gpf Flush, Elongated Bowl, Rear Spud Location, 3/4 in Inlet Spud, 2 in NPTF Outlet Tap, 80 psi Working, Wall Mounting, Vitreous China, White, 18-7/8 in W x 14-1/8 in D x 26-1/8 in H Dimensions, Import
Type
|
:
|
Universal
|
Collection
|
:
|
Washbrook™ FloWise®
|
Flush Rate
|
:
|
0.125/1 gpf
|
Bowl Shape
|
:
|
Elongated
|
Spud Location
|
:
|
Rear
|
Inlet Spud Size
|
:
|
3/4 in
|
Outlet Tap Size
|
:
|
2 in NPTF
|
Working Pressure
|
:
|
80 psi
|
Mounting Type
|
:
|
Wall
|
Material
|
:
|
Vitreous China
|
Finish/Color
|
:
|
White
|
Dimensions
|
:
|
18-7/8 in W x 14-1/8 in D x 26-1/8 in H
|
Domestic/Import
|
:
|
Import
|
- Ultra-high efficiency low consumption, operates in the range of 0.125 to 1 gpf
- Flushing rim
- Elongated 14 in rim from finished wall
- Washout flush action
- Extended sides for privacy
- Fixture only
-
Data/Spec Sheet-1
https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/American_Standard_6515_001_020_Data_Sheet.pdf
-
Instruction/Installation Manual
https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://assets.unilogcorp.com/2/ITEM/DOC/American_Standard_6515001020_Manual.pdf
-
Specification Sheet
https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://assets.unilogcorp.com/2/ITEM/DOC/American_Standard_6515001020_Specification_Sheet.pdf
-
Specification Sheet
https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://assets.unilogcorp.com/2/ITEM/DOC/American_Standard_6515_001_020_Specification_Sheet.pdf
-
Specification Sheet
https://www.texasplumbingsupplyinc.com//ASSETS/DOCUMENTS/ITEMS/EN/https://cdn-assets.unilogcorp.com/ASSETS/DOCUMENTS/ITEMS/EN/American_Standard_6515_001_020_Specification_Sheet.pdf
