Anvil® Swivel Ring, Adjustable, Series: FIG 69, 1/2 to 1 in Pipe, 300 lb, 3/8 in Rod, 650 deg F, Carbon Steel, Pre-Galvanized Zinc, Domestic
| Type | : | Adjustable |
| Series | : | FIG 69 |
| Pipe Size | : | 1/2 to 1 in |
| Load Capacity | : | 300 lb |
| Rod Size | : | 3/8 in |
| Temperature Rating | : | 650 deg F |
| Material | : | Carbon Steel |
| Finish | : | Pre-Galvanized Zinc |
| Domestic/Import | : | Domestic |
- Threads are countersunk so that they cannot become burred or damaged
- Knurled swivel nut provides vertical adjustment after piping is in place
- Captured swivel nut in the 1/2 through 6 in sizes
- The capture is permanent in the bottom portion of the band, allowing the hanger to be opened during installation if desired, but not allowing the nut to fall completely out
- Pre-galvanized zinc strap
- Zinc plated nut
